10 Tonne Mobile Cable Railway Handling Vehicle
| Place of Origin | Henan,China |
|---|---|
| Brand Name | BEFANBY |
| Certification | CE,SGS,ISO9001 |
| Model Number | KPT-10T |
| Minimum Order Quantity | 1 set/sets |
| Price | Negotiation |
| Packaging Details | The Automatic Transfer Robot AGV will be packed by the tarp, the parts will be shipped in the high quality wooden case. |
| Delivery Time | 20-30 days as usual delivery |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 1500 set/sets, per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Power | Battery Powered | Warranty | 24 Months |
|---|---|---|---|
| Load Capacity | 1-1500 Ton | Application | Workshop, Production Line,factory |
| Running Ways | Trackless,no Rail | Power Supply | Lithium Battery Power, Optional Power Supply |
| Characteristic | Self Propelled | ||
| Highlight | 10 Tonne Railway Handling Vehicle,Mobile Cable Railway Handling Vehicle,10 Tonne Motorized Transfer Trolley |
||
Product Description
10 Tonne Mobile Cable Railway Handling Vehicle
Product Description
The working principle of the drag chain rail transfer cart is to drive the chain system through the motor, and the chain transports the materials from the starting point to the end point. Usually the chain is connected to the cargo platform on the trailer, and the material is pushed on the track by the traction of the chain.
- Drive system: The driving part of the drag chain rail transfer cart is usually composed of a motor and a reducer. The motor provides power and the reducer controls the speed.
- Chain system: The drag chain is connected between the car body and the motor to transmit power to the cargo platform.
- Track system: The drag chain rail transfer cart usually needs to be equipped with a special track and run along the preset track. The track is equipped with a chain track and a guide device to ensure that the car body moves smoothly along the track.
- Cargo platform: According to needs, the car body can be equipped with a flat plate, V-frame or other forms of cargo platform for placing various materials to ensure transportation safety.
The drag chain rail transfer cart is very suitable for long-distance and heavy-load material handling equipment, especially for industrial production lines, warehouses, logistics centers and other environments. Its high efficiency, stability and automation make it an indispensable key equipment in modern manufacturing and logistics industries.
Application
Parts Details
Product Parameter
| Model | AGV-2T | AGV-5T | AGV-10T | AGV-20T | AGV-30T | AGV-40T | AGV-50T | |
| Rated load(t) | 2 | 5 | 10 | 20 | 30 | 40 | 50 | |
| Table Size | Length(mm) | 2000 | 2500 | 3000 | 3500 | 4000 | 5000 | 5500 |
| Widthmm) | 1500 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | |
| Heigth(mm) | 450 | 550 | 600 | 800 | 1000 | 1200 | 1300 | |
| Wheel Base(mm) | 1080 | 1650 | 1650 | 1650 | 1650 | 2000 | 2000 | |
| Wheel Dia.(mm) | Φ200 | Φ280 | Φ350 | Φ410 | Φ500 | Φ500 | Φ550 | |
| Battery Voltage(V) | 48 | 48 | 48 | 72 | 72 | 72 | 72 | |
| Weel Quantity(pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | |
| Max Wheel load(KN) | 14.4 | 25.8 | 42.6 | 77.7 | 110.4 | 142.8 | 174 | |
| Reference Wight(t) | 2.3 | 3.6 | 4.2 | 5.9 | 6.8 | 7.6 | 8 | |
Running Route
